CCL Die Cast Tubular Cam Lock
Sku: C-520L
5/8" Die Cast Tubular Cam Lock - Keyed Different Details
KEYED DIFFERENT(KD) = EACH LOCK WILL BE A DIFFERENT LOCK NUMBER.
5/8" Die Cast Cam Lock with 2 keys - Keyed different.
5/8" Die Cast Cam Lock with 2 keys - Keyed different.
Price: $24.07
Only 12 left in stock.
SKU: C-520L-KD
Free shipping not eligible
Shipping charges will apply to this item.
SKU: C-520L
Product Description
Features & Benefits:
- Material: Zinc die cast
- Operation: Push key and turn 90 degrees to desired position for locking and unlocking. Key removeable at 12:00 position only.
- Specifications: Miniature tubular cam lock with removable style cam only. Engineered for use in metal or fiberglass products.
- Mechanism: 4 Pin tumbler mechanism utilizing a tubular key which offers 150 combinations.
- Compact Design - Fits Tight Spaces
- Standard chamfered head design
- Cam Nut
- Mounting Nut
- 1-1/8" x 1/8" Offset Cam
- 1-1/8" straight cam
